What Does 27 MHz Mean on an RC Car? Frequencies, Channels and Upgrading

RC Cars

“27 MHz” on an RC car tells you the radio frequency its remote uses: the 27 MHz band (about 26.995–27.255 MHz), one of the oldest bands for radio control. On toy cars it means the remote and car must be on the same frequency, and that two cars on the same 27 MHz channel will interfere with each other. In hobby radios it means a crystal-based AM or FM system with a handful of channels. Modern RC cars mostly use 2.4 GHz instead, which binds remote and car digitally so many can run at once.

Updated: October 20264 min read

Illustration: 27 MHz RC car remote – SwellRC RC Cars guide

The 27 MHz band

In the US, 27 MHz RC uses six channels, each with a colour code (brown, red, orange, yellow, green, blue) shown by a flag or sticker on the antenna, so drivers could see who was on which channel. Other countries use similar 27 MHz channels with their own rules. Each channel is a fixed frequency set by a matched pair of crystals in the transmitter and receiver. Toy cars often come in a “27 MHz” and a “49 MHz” version so two cars can race without interfering.

27 MHz vs 2.4 GHz

27 MHz 2.4 GHz
Channel selection Crystals or fixed; few channels Automatic frequency hopping
Cars running together Only on different channels Dozens at once
Antenna Long telescopic Short
Interference From CB radios, other cars, electrical noise Much less
Through water Better (used in submarines) Poor
Today Old toys, vintage hobby cars Almost all new cars

Typical 27 MHz problems

  • Glitching: another car or a CB radio on the same channel, or a weak transmitter battery.
  • Short range: antenna not fully extended or damaged; receiver antenna cut short.
  • Car responds to another remote: both use the same 27 MHz channel.
  • Nothing works after battery change: check the crystal is seated and both are on the same channel.

Fixes

  1. Fit fresh batteries in the remote and car.
  2. Fully extend the transmitter antenna; don’t coil or cut the receiver wire.
  3. On hobby radios, swap to a different channel with a matched crystal pair (Tx and Rx crystals must match and be the same AM/FM type).
  4. For toys, choose a second car on a different frequency (27 vs 49 MHz or a different channel letter).

Upgrading to 2.4 GHz

Hobby cars with standard servos and ESCs can be upgraded simply by installing a new 2.4 GHz radio and receiver; the car’s servo and ESC plug straight in. Toy cars usually have the receiver and motor control on one board, so upgrading means replacing that board with a hobby receiver, a small ESC and a servo, which is often more work than the car is worth. Whether another remote can drive your car is covered in can I use a different remote for my RC car.

Is 27 MHz still used?

Yes, in cheap toys, some vintage hobby radios kept for originality, and RC submarines, where lower frequencies reach further through water. Rules on which frequencies may be used for RC differ by country; check before buying old radios abroad. Radio types are compared in types of RC controllers.

Buying tips

  • For a new car, choose 2.4 GHz unless you need a specific vintage setup.
  • Buying two toy cars to race: make sure they’re on different frequencies.
  • Used hobby radios: check the crystals and AM/FM type match.
  • Keep spare crystals on a different channel for club days.

FAQ

What does 27 MHz mean on a toy car?

The radio frequency its remote uses.

Can two 27 MHz cars run at once?

Only on different channels.

Is 2.4 GHz better than 27 MHz?

For cars, yes: less interference and many cars at once.

Can I use a 49 MHz remote with a 27 MHz car?

No, the frequencies must match.
