RC Plane Stands: Types, DIY Builds and What to Look For
An RC plane stand holds your model securely while you assemble it, start the engine, program the radio, fix it or display it. There are four main types: work cradles (padded U-shaped supports for the fuselage), foam blocks, adjustable “pit stands” that tilt and rotate, and display stands for the shelf or wall. A good stand protects the plane from scratches and rolling, keeps the prop pointing safely away, and folds flat for the car. Many modellers build their own from wood, PVC pipe and foam.
By Kyle HilsonUpdated: October 20264 min read
Types of stands
| Type | Best for | Notes |
|---|---|---|
| Cradle (padded U-supports) | Field use, engine starting | Simple, folds flat |
| Foam blocks | Small foam planes, workbench | Cheap, light |
| Adjustable/rotating pit stand | Building, repairs, inverted work | Rotates to reach the underside |
| Display stand | Shelf or desk display | Angled pole, looks like flight |
| Wall hangers | Storage | Saves floor space |
What to look for
- Size: supports wide enough for the fuselage and spaced to share the weight.
- Padding: soft foam or carpet so covering and paint don’t scratch.
- Stability: wide base; it shouldn’t tip when an engine runs.
- Height: comfortable for work; prop well above the ground.
- Portability: folding or light for field use.
- Fuel and oil resistance: easy to wipe clean for glow models.
Build a simple stand
- Cut a base board about 60 cm long and 25 cm wide from plywood.
- Cut two uprights in a U shape to fit your fuselage, with the front one shorter so the nose sits lower (or higher for tail work).
- Screw or hinge the uprights to the base; hinges let it fold flat.
- Glue foam pipe insulation or carpet on the U-shapes.
- Add a strap or bungee to hold the plane during engine runs.
- Seal the wood with paint or varnish against fuel and oil.
A PVC pipe version works too: elbows and tees make a light, adjustable frame that’s easy to take apart.
Using a stand safely
When starting an engine or testing a motor, keep everyone out of the prop arc, strap the plane down or have a helper hold it, and never reach over or in front of the prop. Remove the prop for radio programming and ESC calibration. Prop safety basics are in how to install a propeller on an RC plane.
Display and storage
Display stands with an angled rod make a model look like it’s flying and keep it off shelves where it could be knocked. For larger collections, hanging planes from the ceiling or wall frees space and protects wings; see how to hang RC planes.
Choosing checklist
- Fits your largest fuselage.
- Padded supports.
- Stable base for engine runs.
- Folds or breaks down for transport.
- Easy to clean.
Tips from the field
Put a towel or mat under the stand on grass to catch small screws. Keep a separate, lighter stand for foam planes, and mark your stand clearly at club fields where many look alike. A small tray or magnetic dish on the base keeps tools and parts in one place.
Buying versus building
Commercial stands cost more than a home-made one but often add useful features: rotating cradles, tool trays, fuel-proof surfaces and quick folding. A home-made stand can be made to fit your exact plane and costs little. Many modellers end up with both: a sturdy bought stand in the workshop and a light home-made cradle in the car.
FAQ
Do I need a stand for an RC plane?
Not essential, but it makes assembly and engine starting safer and easier.
What’s the best material for a DIY stand?
Plywood or PVC pipe with foam padding.
Can I use a stand for display?
Display stands are designed for that; work stands can be used too.
How do I protect the covering?
Pad the supports with foam or carpet.
