Heewing F-01: The 690 mm EPP FPV Flying Wing Explained
The Heewing F-01 is a small FPV flying wing (delta wing) with a 690 mm span made of EPP foam with carbon reinforcement. The bare airframe weighs about 190 g and flies at 350–850 g depending on equipment. It uses a 2205-size motor (FX-2205 2350KV) on 2S–4S and is sold as a kit, PNP and PNP Pro (with flight controller), and is designed to take digital FPV systems such as the DJI air units.
By Kyle HilsonUpdated: October 20263 min read
Specifications
| Item | Value |
|---|---|
| Wingspan | 690 mm |
| Length / height | 415 mm / 88 mm |
| Airframe weight | about 190 g |
| Flying weight | 350–850 g |
| Motor | FX-2205 2350KV, 2S–4S, max ~450 W |
| Prop | 6×4 two-blade |
| Material | EPP with plastic parts and carbon spars |
| Versions | Kit, PNP, PNP Pro (flight controller) |
From Heewing and dealer listings, checked October 2026. The maker also claims top speeds over 220 km/h, a minimum speed under 27 km/h, endurance over 70 minutes and range over 45 km; these are best-case figures with specific setups, not typical flights.
What it’s good at
- Small and tough: EPP bends rather than breaks; easy to carry in a backpack.
- Wide speed range: slow enough for hand launch, fast with 4S.
- FPV-ready: designed around a camera and video transmitter, including DJI digital units.
- Efficient: a light wing with a modest battery can fly long cruising flights.
- Vertical take-off design: the wingtips allow it to stand on its tail for take-off.
Which version
Kit: airframe only; for builders with their own electronics. PNP: motor, ESC and servos installed; add receiver, battery and FPV gear. PNP Pro / with flight controller: includes a flight controller for stabilisation and GPS-based modes (with a GPS module), which most new FPV wing pilots should choose.
Setup tips
- Set the centre of gravity exactly as the manual states; wings are sensitive to CG.
- Check elevon direction: both up for pitch up, opposite for roll.
- Start with moderate throws and some expo.
- Configure failsafe to return-to-home (with GPS) or a gentle circle descent.
- Range-test the control link and video before longer flights.
Flying and range
Launch with a firm throw slightly upward at part-to-full throttle. FPV flying in many countries requires a spotter, and flying beyond visual line of sight is generally not permitted for hobby pilots. Long-range claims depend on rules as much as on the plane: see how far an RC plane can fly. Check registration rules too; weight with FPV gear may exceed 250 g.
Why EPP
EPP foam survives hard landings and tree strikes that would crack EPO, which matters for a wing that’s often belly-landed in fields. The trade-off is a rougher surface and more flex, which the carbon spars counter. Foam choices are compared in best foam for RC planes.
What else you need
Besides the PNP plane you need a receiver for your radio (ExpressLRS and similar long-range links are popular), a LiPo or Li-ion pack that fits the battery bay, and FPV gear: a camera, video transmitter and goggles, or a DJI-style digital unit with matching goggles. A GPS module adds return-to-home with a supported flight controller. Budget for spare props and a second battery; most pilots carry two or three packs per session. Weigh the finished plane, since that decides which registration rules apply.
FAQ
What battery does the Heewing F-01 use?
2S–4S LiPo or Li-ion, chosen by speed and flight time.
Is it good for beginners?
For FPV newcomers with a stabilised flight controller and some line-of-sight experience.
Can it carry a DJI air unit?
Yes, it’s designed for digital FPV systems.
Is it a helicopter?
No, it’s a fixed-wing flying wing.
