Eachine E200 RC Helicopter: Specs, Setup and Who It Suits
The Eachine E200 is a 6-channel collective-pitch helicopter with a flybarless head, a 425 mm rotor diameter and a flying weight of about 430 g. It uses dual brushless direct-drive motors (a 4006 630KV main motor and an 1104 4200KV tail motor), runs on a 3S 11.1 V 1350 mAh LiPo for about 7–10 minutes, and has a 6-axis gyro system with stabilised modes. It’s styled as a 1:47 scale helicopter and sits between micro helis and 450-size models.
By Kyle HilsonUpdated: October 20264 min read
Specifications
| Item | Value |
|---|---|
| Rotor diameter | 425 mm |
| Length / height | 420 mm / 120 mm |
| Weight | about 430 g |
| Main motor | 4006 630KV brushless, direct drive |
| Tail motor | 1104 4200KV brushless |
| Battery | 3S 11.1 V 1350 mAh 30C |
| Flight time | about 7–10 minutes |
| Control | 6CH, 2.4 GHz, 6-axis gyro (3D6G) |
From Eachine and retailer listings, checked October 2026. A “Pro” version has also been sold; check which one you buy.
Flight modes
Like similar helicopters, the E200 offers a stabilised mode that levels the helicopter when you release the sticks, and a 3D mode for full manual flight with inverted capability. Start in the stabilised mode, switch to 3D only at a safe height, and keep a thumb near the throttle-hold switch. Read the manual’s mode table, since switch positions vary between versions.
Setup checklist
- Charge the 3S pack fully with a balance charger.
- Check that the blades are tight but can swing back if they strike.
- Power the remote first, then the helicopter, and keep it still for gyro initialisation.
- Check throttle hold is on before plugging in, and off only when ready to fly.
- Move each stick and watch the swashplate respond correctly.
- Do the first hovers over grass or carpet.
Who it suits
- Pilots who can hover a micro collective-pitch heli and want something larger and more stable in a breeze.
- Beginners willing to practise on a simulator and start in stabilised mode.
- Indoor flying in large halls; outdoors in light wind.
Not a good first heli for children: blades are large and fast enough to hurt. Smaller options are compared in micro RC helicopters.
Parts and repairs
Crashes typically break main blades, the main shaft, the tail boom or tail rotor, and canopy mounts. Buy spares with the helicopter, as shipping times for parts can be long. Check the ball links and servos after any hard landing, and replace bent shafts rather than straightening them.
Alternatives
Smaller helicopters like the XK K110S are cheaper to crash and good for learning indoors. Similar-size models from other makers, such as OMPHobby’s range, compete on parts availability and flight quality. Compare parts prices and availability where you live before deciding.
Flying tips
- Set a timer at 5–6 minutes to protect the battery.
- Learn tail-in, side-in and nose-in hover in stabilised mode first.
- Practise on a simulator to save parts.
- Fly away from people; use a landing pad outdoors.
Why direct drive matters
On the E200 the main rotor is driven directly by its brushless motor, with no gears between motor and rotor shaft. That means fewer parts to strip in a crash, less noise and less maintenance than geared helicopters. The tail rotor has its own brushless motor, which the gyro speeds up or slows down to hold heading. The flip side is that a hard crash can bend the motor shaft, and replacing a motor costs more than replacing a gear. Throttle hold, used the moment a crash is unavoidable, protects the motors and the electronics.
FAQ
What battery does the Eachine E200 use?
A 3S 11.1 V 1350 mAh LiPo.
Can the E200 fly 3D?
Yes, in its 3D mode with collective pitch.
Is the E200 good for beginners?
For beginners using its stabilised mode and a simulator, with care.
How long does it fly?
About 7–10 minutes per battery.
