3D flat foam airplanes (“profile foamies”) are aerobatic models cut from flat sheets of EPP or Depron foam, usually 24–43 inches in span and 160–850 g in flying weight. Their huge control surfaces and very low wing loading let them hover on the propeller, flip and fly slowly indoors, and EPP versions survive crashes that would break a balsa model. Popular examples are the Twisted Hobbys / RC Factory Crack Yak-55 series. Here are the sizes, the gear they need and how to pick one.
By Kyle HilsonUpdated: October 20264 min read
What is a 3D flat foam airplane?
A flat foam (“profile”) plane has a flat-sheet wing and a single flat fuselage instead of a 3D body. That keeps it extremely light. Combined with control surfaces that cover up to half the wing and tail and deflect 45° or more, it can fly the slow, high-angle 3D manoeuvres: hover, harrier, torque roll, rolling circles, waterfalls.
- EPP (expanded polypropylene) bends instead of breaking. Best for learning 3D and for crash-prone indoor flying.
- Depron / XPS sheets are stiffer and lighter per strength but dent and snap. Common for scratch-built profile planes.
- Foamboard with a paper skin is cheap and easy to source but heavier and dislikes moisture.
Common sizes and specs
The Crack Yak-55 family shows how flat foamies scale up (manufacturer figures from Twisted Hobbys, checked October 2026):
| Model | Span (in) | Flying weight (g) | Motor | Where it flies |
|---|---|---|---|---|
| Crack Yak-55 Mini | 24 | – | micro outrunner | Gym, small hall |
| Crack Yak-55 Lite | 32 | 160–175 | CSP 2203 1800 kV | Gym, calm outdoor |
| Crack Yak-55 | 32 | 204 | Vertex VS28-05B 1550 kV | Indoors and calm outdoor |
| Crack Yak-55 39″ | 39 | 375–390 | CSP 2213 1100 kV | Outdoor, light wind |
| Crack Yak-55 XL | 42–43 | 765–850 | larger outrunner on 3S | Outdoor |
The rule of thumb for 3D: thrust should exceed flying weight (a thrust-to-weight ratio of 1.5:1 or more) so the plane can hang on the prop and climb out of a hover. The method for sizing motor and prop is in sizing an electric motor for an RC airplane.
What electronics does a flat foamy need?
| Part | Typical for a 32″ profile | Why |
|---|---|---|
| Motor | 22xx outrunner, 1500–1800 kV | Enough thrust on 2S for hovering |
| ESC | 10–16 A | Small and light; headroom for hover current |
| Servos | 4 × 5–9 g digital micro servos | Fast, precise centring for 3D |
| Battery | 2S 300–450 mAh LiPo | Weight decides indoor performance |
| Propeller | Slow-fly prop, around 8–9 in for 22xx motors | Big prop wash over the tail for control in a hover |
| Receiver | 4-channel micro receiver, ideally with a stabiliser | Gyro modes make hovering much easier to learn |
Kit, ARF or scratch build?
- Kit (EPP, printed): pre-cut parts, carbon rods, control horns; you glue, hinge and install electronics. Build time is a few evenings.
- Scratch build: free or paid plans printed on paper, cut from 6 mm Depron or EPP with a sharp blade. Stiffen the wing with carbon strip and the fuselage with carbon rods; profile planes flex otherwise.
- Glue: foam-safe CA or UHU Por for Depron, hot glue for foamboard, and for EPP a contact glue or foam-safe CA. Normal CA melts many foams; the glue table is in building with Depron.
- Hinges: tape hinges or fibre-reinforced tape; 3D needs throws beyond 45°, so hinge gaps must be clean.
Are flat foamies good for beginners?
Not as a first plane. They react sharply, fly in all directions and need practice in orientation. Learn basic flying on a trainer or a slow flyer first (see best slow-flying RC planes). As a second plane for learning aerobatics they are ideal: cheap, light, very hard to break and flyable in a sports hall in winter.
- Set dual rates: a low rate with about 15–20° throw for normal flight, high rate with full 3D throws.
- Add 30–60 % expo on high rates to soften the centre stick.
- Balance at the CG shown on the plans; tail-heavy profiles are twitchy.
- Practise hovering high enough to recover but low enough to see the plane’s attitude.
FAQ
What are 3D foam planes made of?
Mostly EPP foam (bends without breaking) or Depron/XPS sheets (lighter and stiffer but more fragile), stiffened with carbon rods or strips.
What motor size for a 210 g flat plate airplane?
A 22xx outrunner around 1500–1800 kV on 2S with a slow-fly prop of around 8 inches gives more thrust than weight, which is what a 3D profile needs. The 204 g Crack Yak-55 uses a 1550 kV 28 mm motor.
Can I fly a flat foam plane outdoors?
Yes, in calm air. Light indoor versions blow around in any wind; 39–43 inch models with heavier gear handle light wind better.
Which foam plane survives crashes?
EPP models. They flex on impact and are glued back together in minutes.
